Component Item | Qty Per Component | Recommended Qty | Qty |
|---|---|---|---|
| BLOCK, .75 X 3.50 X 8.00 0561076 | 1 | 1 | |
| BLOCK, .75 X 1.00 X 4.62 STL 0561185 | 4 | 4 | |
| BLOCK, .75 X 2.75 X 9.00UHMW 0561248 | 1 | 1 | |
| BUSHING, COMPOSITE 0961948 | 2 | 2 | |
| BUSHING, COMPOSITE 1 3/4" 0961949 | 4 | 4 | |
| PLATE,CLAMP 1001106758 | 3 | 3 | |
| SHIM,NEOPRENE 1001106759 | 3 | 3 | |
| POWER TRACK,GX550-PR-75-105.00 1001107153 | 1 | 1 | |
| CLAMP,HOSE (PLATE) 1001110500 | 1 | 1 | |
| CLAMP,HOSE (RUBBER) 1001110501 | 1 | 1 | |
| BRACKET,WELDMENT LH 1001151542 | 1 | 1 | |
| BRACKET,WELDMENT RH 1001151586 | 1 | 1 | |
| PIN,NICKEL PLATED 1001158810 | 2 | 2 | |
| CABLE, CONTROL 18/2 37 FT 1061033 | 1 | 1 | |
| CLAMP,BLOCK 2.00X11.31 1320243 | 1 | 1 | |
| CLAMP,NYLON HOSE/CABLE 1320314 | 1 | 1 | |
| COVER, .08 X 18.38 X 24.12A569 1670768 | 1 | 1 | |
| COVER, 16GAX7.83X9.33 A569 1670824 | 1 | 1 | |
| DECAL, 600A 1702818 | 2 | 2 | |
| DECAL, DUAL CAP (DOM1) 1704096 | 2 | 2 | |
| DECAL,WARNING DUAL CAPACITY 1707014 | 1 | 1 | |
| ASSY,HYDRAULIC HOSE 2752462 | 1 | 1 | |
| HOSE HYD .50X60.00 STRX90 2752497 | 1 | 1 | |
| ASSY,HYDRAULIC HOSE 2752579 | 1 | 1 | |
| ASSY,HYD HOSE 2752601 | 3 | 3 | |
| ASSY,HYD HOSE 2752604 | 2 | 2 | |
| HOSE HYD .38X546.00 STRXSTR 2752636 | 1 | 1 | |
| HOSE, .50X360.00 STRXSTR 2752939 | 2 | 2 | |
| HOSE, .25X368.00 STRXSTR 2752987 | 1 | 1 | |
| ASSY,HYD HOSE 2752989 | 2 | 2 | |
| HOSE, .25X389.00 STRXSTR 2752990 | 1 | 1 | |
| HOSE, .25X318.00 STRXSTR 2752991 | 1 | 1 | |
| HOSE HYD .38 X 564.00 STRXSTR 2753046 | 1 | 1 | |
| HOSE, .38X362.00 STRXSTR 2753055 | 2 | 2 | |
| HOSE, .38X320.00 STRXSTR 2753056 | 1 | 1 | |
| HOSE, HYD .38X88.00 STRXSTR 2753134 | 1 | 1 | |
| HOSE ASSY, HYD 2753135 | 1 | 1 | |
| PAD, 2.00 X 2.25 X 5.12 3340764 | 2 | 2 | |
| PAD, .75 X 3.00 X 7.38 UHMW 3340787 | 1 | 1 | |
| PAD,WEAR .75X2.50X8.00 3340871 | 4 | 4 | |
| PAD,WEAR .62X2.50X6.00 3340881 | 12 | 12 | |
| PIN, 1.00 X 14.75 1045 3422565 | 1 | 1 | |
| PIN, 1.50 X 14.87 1045 3422572 | 2 | 2 | |
| PIN, 1.75 X 12.87 1045 3422573 | 1 | 1 | |
| PIN,1.75X8.69 1045 3422575 | 1 | 1 | |
| PIN, 1.50 X 10.62 1045 3422576 | 1 | 1 | |
| PIN, 1.00 X 9.75 1045 3422577 | 1 | 1 | |
| PIN, 1.0 X 8.06 1045 3422578 | 1 | 1 | |
| PIN, WELD MASTER TO FLY 1045 3422580 | 1 | 1 | |
| PIN, FLY NOSE 1.25 X 8.50 1045 3422582 | 1 | 1 | |
| COVER, PLATE 3539228 | 1 | 1 | |
| PLATE, .06 X 7.00 X 8.00 A569 3539779 | 1 | 1 | |
| PLATE,.18X2.00X11.31,A569 HR 3570374 | 1 | 1 | |
| PLATE,.19X1.00X4.63,30-54 KSI 3570375 | 4 | 4 | |
| STRAP, HOSE LOOP 3841340 | 2 | 2 | |
| SWITCH, LIMIT ROLLER LEVER 4360578 | 1 | 1 | |
| TAPE.12 X 1.00 X 108FT ACFOAM 4420060 | 10 | 10 | |
| CONNECTOR, 4 POLE 250 V 30 A M 4460959 | 1 | 1 | |
| CONNECTOR, 4 POLE 250 V 30 A F 4460960 | 1 | 1 | |
| CABLE, CONTROL BOOM 45.5 FT 4922493 | 1 | 1 | |
| CABLE, CONTROL 1060896 35.5' 4922494 | 1 | 1 | |
| CABLE, GEN, 1060945, 47' 4922810 | 1 | 1 | |
| CABLE, GEN, 1060945, 34' 4922811 | 1 | 1 | |
| CABLE, CONTROL 18/2 18 FT TERM 4922890 | 1 | 1 | |
| CABLE, CONTROL 18/2 37 FT TERM 4922891 | 1 | 1 |
